A stunning UNUSED Myford VME, variable speed milling machine for sale. Bought by a friend of Chris Moore, this machine came from the original Myford Nottingham factory, was delivered, kept in a headed workshop, and has not been used. Even the plastic flim covering the maker's plate, speed plate (on control panel), and on the tilt/rotating axis graduations is still present and in tact.

PLEASE NOTE: There is also a large BLUE drip tray present that wraps round the 3 sides. It has a nice tall, angular lip. Was removed for safe transport but we do have it. See last photo (Orange) showing how it will look.

The new owner will be a proud person, probably the only new example in the country.

This is the much desired variable speed model having a larger table than the VMC.

Also has Table power feed facility, an excellent option.

Table is unmarked, as you would expect.

The machine is imperial.

Specification below

  • Table size is 760mm x 180mm.
  • Table travel 495mm x 190mm.
  • Spindle is R8
  • 9 spindle speeds 195, 340, 355, 525, 650, 595, 1430, 1545, 2340.
  • Knee travel vertical 310mm
  • Head swivel 45 degree either side of zero
  • Throat depth to machine column is 170mm
  • Maximum quill stroke is 82mm
  • Variable speed
  • 387Kg machine weight
  • Min height from table to spindle nose is 25mm
  • Max height from table to spindle nose is 336mm
  • T slots 3 off, 14mm, distance between is 55mm

For machine dimensions I can email you a photo showing all dimensions of machine and base.

I can not stress just how unlikely it is that I you will ever find another unused example. There are just a couple of very minor chips of paint from storage/moving, bottom edge of base.

Currently sat on a strong pallet and we have the facility to fork lift it into your van or onto your trailer. The pallet is 1.2M x 1.0M. The head could be removed to reduce the height if desired but was collected with the head attached and was absolutely fine if strapped down well with proper heavy duty straps. We will assist with help where we can.



Price:  £ RESERVED. (no additional VAT to add)
