Verey good condition Cowells ME90 for sale. An original lathe with smooth running motor and no nasty hacksaw marks on the back edge of the bed that you see with so many examples. Will need new owner to set the saddle, cross and top slide gib strip pressures to suit their personal preference.
We often have a selection of the following accessories for sale
separately if you are interested. Please call on 01225 812155 or 07753 610420 to discuss currently available accessories.
* Spare tailstock
* Indexing gear
* Fixed steady
* Travelling steady
* Dividing head and plates
* Indexing unit
* Tip over tool rest
* Set of change wheels
* 4 jaw chuck
* Quick change tool post and holders
* Face plate
* Slitting saw and cutting arbor
* Vertical milling slide
* Machine vice
* Roller file rest
* Collet chuck and collets
* Jacot drum and cone set
* Rotating centre
* Tooling
* etc......
Mechanical Dimensions of the Cowells 90 ME Lathe
* Centre height over bed - 44.45mm - 1.75"
* Distance between centres - 203mm - 8.0"
* Swing in Gap - 114mm - 4.5"
* Swing over Crosslide - 47mm - 1.85'
* Crossline Travel - 89mm - 3.5"
* Topslide Travel - 38mm - 1.5"
* Taper in Headstock Spindle: '0' Morse Taper
* Taper in Tailstock Barrel: '0' Morse Taper
* Spindle Nose Thread: 14mm x 1.5mm
* Leadscrew (if selected) & Feedscrew Pitches - 1mm
Overall Dimensions are:
* Height: 225mm
* Length: 500mm
* Width: 300mm
* Weight: 22kg
Price: £ 1,895 (RRP now £4128) (No additional VAT to add)
